A80T Series Hinged Door
The A80T Series Hinged Door features a thermal break aluminum frame for improved insulation and comfort. It supports double or triple glazing with Low-E argon-filled glass, offers strong acoustic performance, and is certified by NFRC and CSA—ideal for residential and light commercial openings.
-
Thermal break system for heat transfer control
-
NFRC & CSA certified product (as shown)
-
U-Factor 0.22–0.32 (noted on sheet)
-
Supports double glazed / triple glazed options
-
Low-E + Argon fill glazing build-ups available
-
Acoustic performance noted: STC/OITC 44/37
-
Standard reference shown: AAMA/WDMA/CSA 101: CW PG40
-
Multiple hinged door configurations available
-
Durable aluminum profiles with precision sealing
-
Modern, wide-opening design for patio / indoor-outdoor use
| Glass | U-Factor (U.S./I-P) | SHGC | VT | CR |
|---|---|---|---|---|
| 6mm double low-E + 12Ar + 6mm double low-E + 12Ar + 6mm clear glass | 0.22 | 0.23 | 0.23 | 67 |
A80T Series Hinged Door CAD
Certifications
FAQs
Is this hinged door energy efficient?
Yes. The A80T uses a thermal break frame and shows U-Factor as low as 0.22 with Low-E argon glazing.
Can I choose double or triple glazing?
Yes. The sheet notes double glazed / triple glazed options, including Low-E + argon-filled build-ups.
What certifications does it have?
The product is shown as NFRC & CSA certified, and references AAMA/WDMA/CSA 101: CW PG40.
Will it help reduce outside noise?
Yes. The listed acoustic rating is STC/OITC 44/37, which supports quieter indoor spaces.
What glass performance values should I consider?
Key values shown include SHGC 0.23 (solar heat control) and VT 0.23 (daylight transmission), balancing comfort and lighting.
What do you need from me to quote accurately?
Opening size (W×H), swing direction (left/right), glazing choice, color/finish, hardware needs, and your project location/requirements.
Performance & Technical Advantages
Sound Insulation
Thermal Insulation
Airtightness
Water-tightness
Wind Resistance
Customization Options For Aluminum Door
Color
Standard colors, matte finishes, custom RAL matching
Glass
Double glazing, triple glazing, Low-E options
Frame
Thermal break profiles, reinforced frame designs
Size
Custom width, height, and proportions available
Hardware
Multi-point locking, enhanced security hardware
Style
Panel configurations and custom sizes matched to project opening requirements.
